제품 상세 정보:
원래 장소: 중국
브랜드 이름: HENGHAO
인증: UL
모델 번호: NTC
결제 및 배송 조건:
최소 주문 수량: 1000
가격: 0.5
포장 세부 사항: 2000PCS/Carton
배달 시간: 10~15WORKDAYS
지불 조건: D/P (지급도 조건), 전신환
공급 능력: 월 10000000

PT100 PT1000 Temperature NTC Thermistor Platinum Thermocouple Prob

설명
Life Cycle: 100000 cycles Voltage & Current: 250V 16A
Contact type: normally closed or normally open Switch type: auto reset or manual reset
하이 라이트:

PT1000 Temperature NTC Thermistor

,

PT100 Temperature NTC Thermistor

,

PT100 Platinum Resistor

PT100 PT1000 Temperature NTC Thermistor Platinum Resistor PT100 Platinum Thermocouple Prob

NTC TEMPERATURE SENSOR

Specification Name Scope Detection Condition
R25(nominal resistance value) 5K,8K,10K,15K to 100K Constant temperature 25℃±0.05℃
R25 Permissible variance(%) ±1,±2, ±3, ±5, ±10 Constant temperature 25℃±0.05℃
B25/50 or B25/85(material coefficient)(thermal-sensitivity index) 2500~5000K

Constant temperature 25℃±0.05℃

Constant temperature 85℃±0.05℃

B25/50 Value permissible variance(%) ±1,±2

Constant temperature 25℃±0.05℃

Constant temperature 50℃±0.05℃

∫(dissipation coefficient) ≥0.8mw/℃ Static in the air
T(thermal time constant) ≤25S Static in the air
Ta(Working temperature) -40℃~+250℃
Pn (rated power) 50mw within working temperature
Case and head   Fork head, O ring head,drops of water head, Metal case, Thread copper case, injection head, or according to client’s drawing
Lead wire   #24 30# 2651, UL4411 28#, double wired conductor and so on, or according to client’s request.
Terminal   Can be riveted according to the requirements of various terminals

Services

PT100 PT1000 Temperature NTC Thermistor Platinum Thermocouple Prob 0

1. Your inquiry will be replied within 12 hours;

2. Well-trained and experienced staff are always at your service.

3. Unique design products and many private mold product are waiting for your choice.

4. Strictly protect your private information and your ideas of design.

FAQ



Q1. Can I have a sample order for SENSOR?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.



Q2. What about the lead time?

A:Sample needs 3-5 days, mass production time needs 1-2 weeks based on the amount of your order.



Q3. Do you have any MOQ limit for led waterproof string order?

A: At least 1 for sample checking is available



Q4. How do you ship the goods and how long does it take to arrive?

A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping are also optional.



PT100/PT500/PT1000 Temperature sensor

Product name PT100 temperature sensor (Thermocouples, hot resistance)
Graduation number PT100, CU50,PT1000,K,E,J,T etc.
Temperature range -50 to 500ºC
Chip imported from Heraeus - Germany
Temperature probe 304 stainless steel, plastic or other according to client's request
Accuracy Grade A Grade (0.1),B Grade(0.3),2B Grade (0.5),1/3 B Grade(0.1)
Temperature probe 4*30mm, or according to client's request to design.
Thermal time constant 0.5S
Lead wire Three core sliver tetrafluoride shielded wire (-50~200ºC)
Silicone wire(-200~200ºC)
Three core high temperature wire(-40~450ºC)
Four fluorine wire (-50~150ºC)
Dia 3mm~16mm
terminal Y type, Pin,XH2.54 or according to client's request.
Level of protection IP68

PT100 PT1000 Temperature NTC Thermistor Platinum Thermocouple Prob 1PT100 PT1000 Temperature NTC Thermistor Platinum Thermocouple Prob 2PT100 PT1000 Temperature NTC Thermistor Platinum Thermocouple Prob 3
